YAMAHA TAIL COVER ASSY KHJ-MC16U-00 SS8MM Feeder Parts
Part Name:YAMAHA TAIL COVER ASSY
Part Number:KHJ-MC16U-00
Model:SS8MM Feeder
YAMAHA TAIL COVER ASSY KHJ-MC16U-00 is for YAMAHA Pick&Place machine SS8MM Feeder.
SMT Spare Parts please see as below,
51 KGB-M71V2-01X SENSOR, STAY R 1 Z2
52 KV8-M71V3-00X BRACKET, LOCK SENSOR 1
53 KGB-M71VC-00X HOLDER PULLEY 1 (2002/1/17) M210074
54 KGB-M71Y1-01X COLLAR 1,PULLEY 1
54-1 90990-41J011 COLLAR 1 (2008/4/15) ME20075 OK
54 KGB-M71Y1-01X COLLAR 1 PULLEY 1
55 90933-01J800 BEARING 2
56 99009-10800 CIRCLIP 1 ISTW-10
57 KGB-M71Y9-00X BODY, CYLINDER 1
58 KV8-M71YA-00X VALVE CLUTCH 4
59 KV8-M71YB-00X PACKING 8
59-1 90990-22J005 PACKING 8 (2002/2/1) M220005 OK
60 91317-05005 BOLT HEX.,SOCKET HEAD 8
60-1 91317-05006 BOLT HEX.,SOCKET HEAD 8 M5X5 (2002/1/8) M210011 OK
61 KM1-M7105-00X PLUG 2 8
62 KM1-M7112-01X STOPPER 1
63 KGB-M7181-00X BELT, HEAD 2
64 92A08-03303 SET SCREW 16 M3X3
65 KM1-M7186-00X O-RING 4 5X1.0
65-1 90990-17J007 O-RING 4 5X1.0 (2001/12/25) M1Y0084 OK
66 KV8-M653F-E0X SENSOR 3 ASSY 4 E2S-Q22 (CLUTCH)
67 KV8-M653F-A0X SENSOR 3 ASSY 4 E2S-Q22 (1,3,5,9)
68 KV8-M653G-A0X SENSOR 4 ASSY 4 E2S-Q22B (2,4,6,8)
69 KV8-M653H-A0X SENSOR 5 ASSY 4 (NOZZLE POS.)
70 KGB-M653A-00X SENSOR HEAD ASSY 3
70-1 KGB-M653A-01X SENSOR HEAD ASSY 3 (2004/3/18) M430057 OK
70-2 KGB-M653A-02X SENSOR , HEAD ASSY 3 (2005/7/21) MB70010 OK
71 KGB-M653F-10X SENSOR, 3 ASSY. 1 EE-SX872P (R-ORG)
72 93604-06083 PIN DOWEL 6 4X6
72-1 90990-20J001 PIN DOWEL 6 (2002/1/9) M1Y0141 OK
72-2 90990-20J001 PIN DOWEL 4 (2002/2/19) M220087 OK
72-3 90990-20J001 PIN DOWEL 5 (2007/2/27) MD10054 OK
73 99480-04008 PIN,PARALLEL 8 4X8
73-1 99480-04008 PIN,PARALLEL 6 4X8 (2007/2/27) MD10054 OK
74 90110-03248 BOLT HEXA.S.H: M3X55 3
74-1 91317-03055 BOLT HEX.SOCKET HEAD 3 (2003/7/15) M370057 OK
74-2 91317-03055 BOLT HEX.SOCKET HEAD 5 (2006/8/11) MC80042 OK
