Philips PA2903/68 56mm CL Tape Feeder 9965 000 15828 Assembleon Feeder
Part Name:Assembleon 56mm CL Tape Feeder
Part Number:9965 000 15828
Applicable Models:Topaz, Topaz X, Topaz XII, Sapphire-Xii, MG1,MG2, Opal XII
Brand: Assembleon
Type:CL56MM
Philips PA2903/68 56mm CL Tape Feeder 9965 000 15828 Assembleon Feeder is applied for Assembleon pick and place machines Topaz, Topaz X, Topaz XII, Sapphire-Xii, MG1,MG2, Opal XII Series.
Assembleons Parts is as below,
Part No. Description
9498 396 00339 PA2903/77 Assembleon 8X2mm Green Handle 0201 CL Tape Feeder
9498 396 00340 PA2903/78 Assembleon 8X2mm Blue Handle 0402 CL Tape Feeder
9498 396 00341 PA2903/79 Assembleon 8X4mm Black Handle CL Tape Feeder
9498 396 00342 PA2903/88 Assembleon 12mm CL Tape Feeder
9498 396 00338 PA2903/27 Assembleon 16mm CL Tape Feeder
9965 000 15825 PA2903/38 Assembleon 24mm CL Tape Feeder
9965 000 15826 PA2903/48 Assembleon 32mm CL Tape Feeder
9965 000 15827 PA2903/58 Assembleon 44mm CL Tape Feeder
9965 000 15828 PA2903/68 Assembleon 56mm CL Tape Feeder
9498 396 01977 PA2903/67 Assembleon 72mm CL Tape Feeder
5322 360 10207 Valve speed select
9965 000 03808 Valve, speed select
5322 360 10208 Valve up/down
9965 000 03807 Valve, up-down select
5322 693 11367 Single ejector
9965 000 09042 Ejector, Single
5322 360 10209 Valve blow-off
5322 281 20202 Single valve
5322 216 04084 Vacuum sensor board
5322 216 04673 Vacuum sensor board
5322 132 00141 Sensor, head down sensing
9965 000 10927 Sensor, head down sensing
5322 132 00036 Sensor Head
5322 132 00132 Sensor W origin
5322 132 00056 Sensor 1-3 (L=1150)
9965 000 06136 Sensor 1-3 (L=1400)
5322 130 10079 Sensor Presure
5322 693 11352 Spline assy (Complete spline shaft assy head 1)
5322 693 11199 Spline assy (Complete spline shaft heads 2-8, indicated with “Y” means 40 um accuracy)
5322 693 11539 Topaz Inner spline shaft heads 2-8
5322 693 11542 Inner Spline, 16 micron
5322 535 10674 Shaft head asyy (shaft head assy head 1-3-5-7 for SF and FNC head)
9965 000 03802 SHAFT NOZZLE HEAD
5322 535 10676 Shaft head assy (spline shaft assy 2-4-6-8 only for FNC head)
9965 000 10930 Spline Shaft, Even Heads, FNC
9965 000 10928 Spline Shaft, even Heads SF
9965 000 10929 Spline Shaft, Odd Heads SF and FNC
9965 000 10928 Spline Shaft, even Heads SF
9965 000 10929 Spline Shaft, Odd Heads SF and FNC
5322 216 04674 I/O Board for Topaz Xii (BD CNV)
9965 000 11067 I/O Core Board for Topaz Xii (BD)
5322 360 10483 Nozzle assy (nozzle assy heads 2-4-6-8)
